前面一篇文章與大家分享了PLC的常見故障點，而這一篇文章則是要分享PLC的常見中英文對照表。相信今天的兩篇文章能為您增加了對PLC的了解和認識度。安徽得潤電氣技術有限公司的PLC和DCS工程師有豐富的經驗和實力，值得您的信賴。

1. PLC 可編程控制器

2. absolute  絕對

3. absoluteoutput   絕對最大輸出
4 .actuator  執行器
5. against  對比
6. allocate  分配
7. alter  改變  修改
8. ambient  環境 周圍 ambient operating temperature
9. analog 模擬   analogoutput
10. analysis 分析 thecollection an and analysis of data
12. applicable 可用  the applicableCPU for the module
13.assign 分配
14.back up battey  備用電池
15.barcode reader/ID  條形碼閱讀器
16.base unit  主基板
17.baud 波特
18. beforehand  事先
19 .binary 二進制
20.buffer memory 緩沖存儲器
21. bus 總線
22. case 外殼 do notremove the module's print board from the case
23. characteristic 特征 I/Ocharacterristic
24. check 校驗 the datalink status canbe checked
25. child-station  子站
26. common terminal   公共端
27. compatible  兼容 compatiblewith the MODBUS protocol
28. compound  混合  compoundsystem communication [`compaund]
29. condensation  結露
30. condition   條件 conditionsetting
31. conductive  導電 conductivemetal picees
32. configuration  組態 systemconfiguration
33. configure  組態
34. confirm  確認 how toconfirm the operation of the module
35. consumption  消耗 currentconsumption
36. content  目錄
37. control level  控制級
38. convenient 方便 moreconvenient and easy-to-use
39. conventionaly  傳統 whichconventionaly has been used
40. conversion 轉換 Analog-Digital conversion module
41. converter  轉換器
42. conveyor  傳送 conveyorline
43. corrosive  腐蝕 corrosivegas
44. countermeasure  對策countermeasure for mis-inpute
45. cutoff  切斷
46. debug  調試 isrecommended before debugging
47. dedicated  屏蔽 cc-linkdedicated cable
48. dedicated  專用 dedicatedtransmission protocol
49. default value  缺省值
50. define  解釋 闡明 Offset value and gain value are defined as follow. [di`fain]
51. design  設計 design asystem
52. device level  現場級
53. diagnosis  診斷 diagnosisfunction
54. digital  數字  digitalinpute
55. DIN rail  導軌
56. diverse  不同的各種各樣的
57. download  下載
58. duplicate  完全一樣
59. dust  灰塵
60. eliminate  免得[i`limineit]
61. enterprise level  管理級
62. erase  清除
63. exceed  超出 The numberadmitted must not exceed 200
64. execute  執行 date linkis executed using these parameters
65. expand  擴展 can beeapanded up to 255 networks
66. faulty 故 障站
67. field bus  現場總線
68. fix  固定
69. flexibly  靈活的 to supporta variety systerm flexibly
70. flow  流量
71. format  格式transmission format [`fo:maet]
72. fuse   融絲
73. graph  圖標 坐標圖曲線圖 voltage output characterristicgraph
74. guaranteed  擔保 nomaloperration cannot be guaranteed
75. handle  處理
76. hardware manual  硬件手冊
77. hint  提示 programminghints
78. humidity  濕度 ambientoperating humdlity
79. individual  獨立的
80. inductance  電感 inductanceload
81. initiate  實施 發起 can be initiate by a computer [i`nifieit]
82. input  輸入
83. input point  輸入點數
84. install  安裝
85. instruction  指令 the FROMinstruction
86. insulation 隔離 form rubberprovides good insulation [,insju`leifn]
87. interface  接口
88. interlocking  互鎖 can be usedfor sequence program interlocking
89. internal external  內部 外部 internal connection
90. interrupt  中斷 excute aninterrupt processing
91. invalid 無效 errorinvalid station function
92. magnetic 有磁性的 magneticfields [maeg`netik]
93. main circuit  主回路
94. malfunction  故障 causesystem malfunction
95. mandatory  強制
96. mantenance  維護 maintenancecosts are reduced
97. manual  手冊 User'Manual
98. mechanical  機械 michanicallife機械壽命
99. module  模塊 mount orremove the module [`modju:l]
100. momentary power failure  瞬時斷電
101. monitor  監視
102. mount  固定 mount orremove the module
103. multiple  多樣 mutipleremote i/o modules
104. negative  負
105. observation 觀察
106. occupy  占用 occupies 1station
107. occur  發生
108. offline  離線 offlinetest
109. offset gain  偏置增益
110. oil mist  油霧
112. optical loop  光纜回路
113. optimum  最佳的 optimumcontrol
114. output  輸出
115. overall  總的 overalldistance
116. overview  總攬communication overview
117. parameter  參數
118. path  路徑transmission path
119. per network
120. perform  進行 normal datalink cannot be performed
121. performance specifations  性能規格
122. peripheral  外圍 Whenutilizing peripheral device to assign I/O number.
123. phase 相 swith offall phases of the power supply [`feiz]
124. point  要點
125. port 接口  Rs232c port
126. positive  正
127.power line 電源線
128. power on/off  上電斷電
129. precaution  注意事項precaution when configuing system
130. print board  印刷電路板
131. procedure  過程 follow theprocedure
132. programing interface  編程口
133. protocol  協議 protocolcommunication issues
134. range  范圍
135. rated input voltage  額定輸入電壓
136. ratio  比率
137. recommend  建議 isrecommended before debugging
138. reduce  減少 the numberof steps in operation program can be reduced
139. refer to  參照 refer toChapter 6
140. register  數據寄存器
141. relay  繼電器 [`ri:lei]
142. remote I/O 遠程網絡
143. reserved station 預留主站
144. resistor  電阻 resistorload阻性負載   terminating resistor
145. resolution  分解，解析 nMaximum resolution   最大分辨率
146. restriction  限制 norestriction [ri`strikfn]
147. retry 重試
148. scan 掃描 link scan
149. screw 螺絲 Teminal-block screw
150. seamless network 無縫網絡
151. sequence programme 順控程序
152. serial communications module 串口模塊
153. series 系列
154. servo 伺服
155. short 短路
156. signal 信號
157. sink 漏極 sink commen
158. slot 槽
159. soures 源極 sourescommen
160. specifications 特性 inputmodules specifications
161. stabilized power supply 穩壓電源
162. standby master station 備用主站
163. start up 起動
164. status 狀態 data linkstatus
165. step drive 步進
166. storage 存儲 storagearea
167. store 存儲
168. switch off 關斷 swith offall phases of the power supply
169. swith 開關
170. table 表格
171. transfer 傳輸
172. transistor 晶體管
173. transmission speed 傳輸速度
174. transmit 傳送 data istransmitted in unchanged code
175. triac 雙端三相可控硅開關
176. troubleshooting 故障處理
177. unuseble 不可以使用
178. upload 上傳
179. utilize 利用 Whenutilizing peripheral device to assign I/O number.
180. verify 校驗 verify theset parameter contents
181. voltage 電壓 highvoltage
182. watchdog 看門狗
183. width 范圍 it willvary in the width of [widθ]
184.  wire chips 線頭
